Aventon Pace 500.3

Aventon Pace 500.3
  • Color: Midnight Black
  • Color: Midnight Black
  • Color: Midnight Black
  • Color: Midnight Black
  • Color: Camoflauge
  • Color: Camoflauge
  • Color: Camoflauge
  • Color: Camoflauge
  • Color: Camoflauge
$1,599.99
$1,699.99
Please select options

Details

Reinvigorate the casual bike ride with Pace 500.3! Feel your efforts amplified with its intuitive torque sensor, then set the pace. How you cruise is up to you. The Pace 500.3’s 500W motor, with a top speed of 28 mph and up to 60 miles in range, gives a whole new meaning to ‘going for a spin’. The all-new turn signal functionality allows you to command traffic with confidence as you enjoy your roll through the neighborhood. Its cushioned saddle, swept-back handlebars, and upright riding position provide the ultimate comfort along the way. Pace 500.3 is leisure with a lift as you switch between its 4 new pedal assist levels: eco, tour, sport and turbo. Take the alternate route, there’s much more to see.

Pace 500.3 comes in 2 sizes to suit most adults.

Regular: 5'3" - 5'10"
Large: 5'10" - 6'4"

Frame Size:                Regular          Large
Top Tube Length:      625mm          662mm
Reach:                            350mm          383mm
Head Tube Length     215mm          225mm
Standover Height      733mm          770mm
Wheelbase                    1094mm         1131mm
Min Saddle Height    760mm          860mm
Max Saddle Height   940mm         1000mm
https://images.prismic.io/aventon/ac21b896-beb2-4a79-8b43-ad5a83b8dfa4_Pace+3+500+Step+Over+S%26F.png?auto=compress,format

Specs

MODEL Pace 500.3 Ebike
MOTOR 500W 48V Brushless Hub Motor
THROTTLE Throttle on demand - Throttle from a complete stop
DISPLAY LCD Smart Easy Read Display with Backlight, Colorful screen with app
SPEED Up to 28 MPH on Pedal Assist
BATTERY Removable Internal Lithium-ion 48V 12.8Ah (614Wh) with LG cells
SENSORS Torque Sensor
PEDAL ASSIST 4 Levels
CHARGER 48V 3 Amp Fast Charger, 4-5 Hour Charging
RANGE Up to 60 Miles* on PAS 30 Miles on Throttle
FRAME 6061 Single-Butted Aluminum Alloy with Internal Battery
WEIGHT 52 lbs
PEDALS 9/16' Alloy Platform
FORK AE-E08-V2 AL Fork
WEIGHT LIMIT 300 lbs
BOTTOM BRACKET Square Taper, Sealed, Torque Sensor
CRANKSET 170mm w/ 48 T
REAR DERAILLEUR 8 Speed
CASSETTE 12-32T, 8 Speed
SHIFT LEVER 8 Speed Trigger
BRAKES Hydraulic Disc Brakes
CHAIN 122 Link, 8 Speed
RIM Double Wall Aluminum 36h Front & Rear
TUBES Butyl Rubber, Schrader Valve
HUBS 36H Disc Nutted Front, Nutted Rear
TIRES 27.5" x 2.1" Puncture Resistant, Reflective Sidewalls
SADDLE Aventon Saddle
SEATPOST Forged Alloy, 30.9mm 2-Bolt Clamp
STEM Threadless, 31.8mm, 90mm
SEAT CLAMP 34.9 mm Quick Release
HANDLEBARS Aluminum 31.8mm, Sweptback
HEADSET Sealed Bearing Headset
GRIPS Ergonomic Comfort
DIMENSIONS Bike Box: 150 cm x 27 cm x 86 cm

* Subject to change without notice.

Part Numbers

Option MPN Store SKU
Midnight Black / Regular 1E038-0024401 210000032385
Midnight Black / Large 1E038-0025001 210000032387
Camoflauge / Regular 1E038-0024406 210000032399
Camoflauge / Large 1E038-0025007 210000032389
