Details
Movement That Moves You.
An ebike that elevates the art of getting around. Function meets pleasure. Comfort meets capability. Speed meets style. From point A to point B, or to no point in particular – it's your best way there.
Where it thrives
- Around town and beyond
What it's built for
- Comfort and Ease
Highlights:
- Low Step-Thru SmartForm C1 Alloy frame/ ultra-smooth 50mm travel HeadShok fork
- Shimano Nexus 5-speed internal gear hub / Gates carbon belt drive
- Bosch Smart System - Performance Line CX Speed drive-unit 28mph / 750Wh battery / Kiox 300 display & remote / Range: up to 108 mi
Bosch 750Wh Battery
Bosch's largest and most powerful e-bike battery. No range anxiety!
28 mph Assist
This e-bike drive system provides pedal assist up to a maximum speed of 28mph. Above that, it’s all you.
Range up to 108 miles
With up to 108 miles of range on a single charge, you’ve got the power to go anywhere and do anything. Have fun. Ride longer.
Smart Power, Big Range
- This e-bike is powered by Bosch’s new Smart System, featuring a huge 750Wh battery, Performance Line Speed CX motor, LED remote and Kiox 300 display. Effortless acceleration, compelling versatility, and a range of up to 108 mi on a single charge.
Roll Smoothly
- When it comes to urban suspension forks, our sleek new HeadShok stands alone. It's a fully rigid structure that telescopes on friction-free needle bearings for a level of smoothness and steering precision that other forks just can't match.
Clean, Quiet and Easy
- The combination of the Gates belt system with a Shimano internal gear hub makes an ideal urban drivetrain. No dirty chains, no noisy derailleurs; just smooth, simple, reliable shifting always.
- Large/X-Large: 5'7" - 6'5"
Frameset
-
FrameSmartForm C1 Alloy, low step-thru, removable 750Wh downtube battery, integrated front running light, tapered headtube, internal cable routing, 135mm QR hub spacing, IS disc mount, motor protection
-
ForkCannondale HeadShok, 50mm travel, Quad Cage needle bearing internals, coil spring, twin chamber semi open-bath oil damping, post mount disc, 110x15mm thru-axle
-
HeadsetIntegrated Sealed Bearing, Tapered, internal cable routing
E-System
-
Drive UnitBosch Performance Line CX Speed, 28mph
-
BatteryBosch PowerTube, 750Wh
-
ChargerBosch 4A
-
DisplayBosch Kiox 300 w/ LED remote
Drivetrain
-
Rear DerailleurShimano Nexus i5e, internal gear hub, 5-speed
-
ShiftersShimano Nexus Revoshift, 5-speed twist shifter
-
ChainGates CDX high performance carbon drive belt
-
CrankGates Bosch E-bike, w/ 46T sprocket
-
Rear CogsGates CDX, 34T
Brakes
-
BrakesRiderever Attack-XU, 4-piston hydraulic disc, 203/203 rotors
-
Brake LeversRiderever Attack-XU hydraulic disc
Wheels
-
Front HubShimano MT400, 15x110mm thru-axle
-
Rear HubShimano Nexus i5e, internal gear hub, 5-speed
-
RimsWTB STX i30 TCS, 32h, tubeless ready
-
SpokesStainless Steel, 14g
-
Tire Size2.0
-
Wheel Size27.5/29
-
TiresContinental eContact Plus w/ reflective sidewalls 27.5x2.20" 55-584 (S/M), 29x2.20" 55-622 (L/XL)
-
Front TireContinental eContact Plus w/ reflective sidewalls 27.5x2.20" 55-584 (S/M), 29x2.20" 55-622 (L/XL)
-
Rear TireContinental eContact Plus w/ reflective sidewalls 27.5x2.20" 55-584 (S/M), 29x2.20" 55-622 (L/XL)
Components
-
HandlebarCannondale Urban Backsweep
-
StemCannondale Urban Intellimount, internal cable routing, SP-Connect compatible phone mount
-
GripsCannondale Ergo Fitness Dual Density, Lock-on
-
SaddleSelle Royal Essenza
-
SeatpostSR Suntour NCX SP12 Parallelogram Suspension Seatpost, 31.6, 300mm (SM/MD), 400mm (LG/XL)
Extra
-
Extra 1Integrated headtube running light, Cannondale Urban rear rack (25kg, Racktime compatible), Curana Apollo fenders, AXA Compactline 35E Front Light, AXA Blueline Rear Light, kickstand*Subject to change without notice.
Part Numbers
Option | UPC | MPN | Store SKU |
---|---|---|---|
Candy Red / Small/Medium / 27.5-inch | 884603975046 | C68044U10SM | 210000036895 |
Candy Red / Large/X-Large / 29-inch | 884603975053 | C68044U10LX | 210000036896 |
