Giant Talon 4

Giant Talon 4
  • Color: Metal
  • Color: Metallic Black
$599.99
Please select options
This item can be purchased online and picked up curbside or in-store at your convenience. Alternatively select "Home Delivery" at checkout and we will deliver to your door.

Details

PUSH THE PACE ON CLIMBS, LET LOOSE ON THE DESCENTS. THIS ALUMINUM HARDTAIL GIVES YOU A FEEL FOR THE TRAIL WITH BALANCED, CONFIDENT HANDLING AND A PLUSH SUSPENSION FORK.

KEY PERFORMANCE FACTORS

Proven alloy performance
ALUXX aluminum frameset is hand-built in-house by the world leader in aluminum engineering.

Balance and stability
Frame geometry is designed to optimize the balance and roll-over capabilities of 29-inch wheels or the liveliness of 27.5-inch wheels (depending on frame size).

XC control
Suspension fork offers either 80mm or 100mm of smooth travel for added XC control.

Wheel size:
Sizes X-Small – Medium: 27.5-inch
Sizes Small – X-Large: 29-inch

Geo Chart

Geometry Chart:
SizeSmallMediumLargeX-Large
SEAT TUBE LENGTH (A) (mm) 390 440 490 535
SEAT TUBE ANGLE (B) 74.0° 74.0° 74.0° 74.0°
TOP TUBE LENGTH (C) (mm) 577 599 620 639
HEAD TUBE LENGTH (D) (mm) 95 105 125 140
HEAD TUBE ANGLE (E) 68.5° 68.5° 68.5° 68.5°
FORK RAKE (F) (mm) 51 51 51 51
TRAIL (G) (mm) 94 94 94 94
WHEELBASE (H) (mm) 1126 1150 1172 1192
CHAIN STAY LENGTH (I) (mm) 455 455 455 455
BOTTOM BRACKET DROP (J) (mm) 55 55 55 55
STACK (K) (mm) 602 611 630 644
REACH (L) (mm) 404 424 439 454
STAND OVER HEIGHT (M) 732 766 805 839
HANDLEBAR WIDTH (N) (mm) 780 780 780 780
STEM LENGTH (O) (mm) 50 60 70 80
CRANK LENGTH (P) (mm) 170 175 175 175
WHEEL SIZE (Q) 29" 29" 29" 29"
Sizes:
SizeRider Height
XS (27.5") 5’1” to 5’5”
S (27.5") 5’4” to 5’8”
S (29") 5’4” to 5’8”
M (27.5") 5’7” to 5’10”
M (29") 5’7” to 5’10”
L (29") 5’9” to 6’1”
XL (29") 6’0” to 6’4”

Specs

Frame ALUXX-Grade Aluminum, disc
Fork SR Suntour XCE, steel steerer
Rims Giant GX03V 29 or 27.5, alloy, double wall, 21mm inner width
Hubs alloy, sealed bearing
Spokes stainless, 14g
Tires Kenda Booster 29x2.2", wire bead
Bottom Bracket cartridge
Crankset ProWheel A10XPP, 32t
Shifters microSHIFT SL-M718, 1x8
Rear Derailleur microSHIFT RD-M619
Cassette/Freewheel microSHIFT CS-H083, 12-46
Chain KMC 8.3
Brakes TKB-172, mechanical [F]180mm, [R]160mm rotors
Brake Levers RS360A, mechanical
Handlebars Giant Connect Trail, 31.8mm
Tape/Grips Giant Sole-O
Stem Giant Sport, 7-degree
Seatpost Giant Sport, 30.9
Saddle Giant custom
Pedals MTB caged
Accessories & Extras 2.4" max tire size

* Subject to change without notice.

Part Numbers

Option UPC MPN Store SKU
Metal / X-Small / 27.5-inch 04712878890633 2221148223 210000025827
Metal / Small / 29-inch 04712878890718 2221149224 210000025955
Metal / Medium / 29-inch 04712878890725 2221149225 210000025949
Metal / Large / 29-inch 04712878890732 2221149227 210000025944
Metal / X-Large / 29-inch 04712878890749 2221149228 210000025963
Metallic Black / X-Small / 27.5-inch 04712878890596 2221148123 210000025829
Metallic Black / Small / 27.5-inch 04712878890602 2221148124 210000025825
Metallic Black / Small / 29-inch 04712878890671 2221149124 210000025958
Metallic Black / Medium / 27.5-inch 04712878890619 2221148125 210000025821
Metallic Black / Medium / 29-inch 04712878890688 2221149125 210000025952
Metallic Black / Large / 29-inch 04712878890695 2221149127 210000025946
Metallic Black / X-Large / 29-inch 04712878890701 2221149128 210000025966
